Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 197

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 197
709. TWO-POLE OR SHUTTLE-SPOOLARMATURE.—Section of spool with end overwinding; usually made of cast iron. … 710. SHUTTLE ARMATURE, made with soft sheet-iron plates riveted to-gether. The strongest current armaturefor small two-pole generators.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
