Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 202

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 202
730. ELECTRIC IGNITER, used onexplosive motors. The bat-teries? B, B. B5 in series; asparking coils T; a braker, kyrevolving on the shaft, theinsulating plug. P^ and ther platinum electrodes, c^ c, with … the wiring, are the principal parts in this device 731. SPARKING DYNAMO, or genera.ojfor a marine gasoline engine. Permanent horse-shoe magnets, with an armature revolved by abelt from the fly-wheel of the engine. With atrue rim on the fly-wheel, the pulley of the gen-erator maybe covered with…
