Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 211

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 211
eet iron or iron wire; S, induc-tion coil of large wire and fewturns; D, lamp circuit. Practi-cally both coils are wound onthe same core. 759A. ELECTRO MAGNETICRATCHET DRIVER.—Used on electricclocks. The flexible iron stirrup is fixed atthe bottom to the frame carrying theratchet wheel. The upper… … Section X, NAVIGATION AND ROADS. Vessels, Sails, Rope Knots, Paddle Wheels, Propellers, Road Scrapers. AND Rollers, Vehicles, Motor Carriages, Tricycles,Bicycles and Motor Adjuncts.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
