Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 219

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 219
^^S^ 804. FISHERMANS BEND HITCH. 805. ROUND TURN AND HALFHITCH. 806. CHAIN STOP for a cable. … :::-s.^^ 807. disengaging hook, held by a mousing link. 808. SLIP. HOOK.—The extension of the sus-I pension link holds the lower link in line, while a pullon the arm by a lanyard releases the load. 809. releasing HOOK.—The lever throws thelink off by a pull of the lanyard.
