Metal-work; a handbook for teachers and students (1914)

Adam, Hugh M. [from old catalog], Evans, James Humphrey, [from old catalog] joint author · New York, Longmans, Green and co.; London, E. Arnold · leaf 278

An illustration from Metal-work; a handbook for teachers and students, 1914, leaf 278
Model 19. the desired part, gripping one end in the vice, and turning thebar with a lathe carrier or tap wrench. Determine and cutoff to exact length, and complete the model by forging thepoint. Model 20—Hook: Mild-Steel.—The pomt of the hook shouldfirst be forged down and ground on the grindstone,… … Model 20. the point bend should be forged. Then cut off to length, andforge the second bend. A template of the hook marked outon a sheet of tin is of great assistance when forging thismodel. Model 21—Bracket: Mild-Steel.—This model is an exercisein cold bending, and before commencing work the…

Metal-work

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
