Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 223

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 223
NAVIGATION AND ROADS. 217 835. REVERSING SCREW PROPELLER.—The centralshaft is the driver, and has a small longitudinal motion by a clutch and lever to shift the position of the blades. Theouter-end sleeve is fast on the driving shaft, andcarries the blades in sockets on each side of itscentre. A…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
