Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 225

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 225
840. SOUNDING WEIGHT RELEASE for deep-sea sounding. A hollow spindle attached to the sound-ing-line encloses a hook lever, sprung out by a spring.A spindle, with an impact head, slides behind the leverand releases the ball at the moment the head strikesthe bottom. 841. SAMPLER SOUND-ING WEIGHT.—The… … 842. Cups closed.
