Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 229

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 229
858. LIGHT ELECTRICCARRIAGE, with singleseat. The motor is attached • to the frame and gearedto a speed shaft, and bysprocket and chain to thewheel axle. 922 NAVIGATION AND ROADS. … 859. ELECTRIC PHAETON.—The motors are fixed to aframe under the floor of thephaeton, with their pinionsmeshing with an inside spurgear on each wheel. Thebatteries are under the seatand extension box over thedriving wheels. 860.
