Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 243

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 243
922. DIFFERENTIAL SCREW ANDGEAR MOVEMENT.—The spur gear E isfixed to a screw hub or nut, revolving in thehead of the short standard. The pinions Fand G vary in size to match the spur gears Dand E. The revolution of the pinions and shaftA, B produces a differential motion in thespur gears E and D. D…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
