Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 253

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 253
of the pulley velocities. If B is the driving shaft, Aand A may be the wheels of a vehicle. 975. DOUBLING A REVOLUTION on thesame shaft, Entwistles patent. The pulley atA is the driver on the shaft D. The bevel gearat A is fixed. The stud E is fast on the shaft.The bevel wheel B revolves freely on… … GEARING. 247
