Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 254

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 254
the shaft A A. Differential mo-tions of the two wheels C D will produce a ro-tation of the arm F G, around and with theshaft A, or, by making the arm loose on the shaft, a differential mo-tion may be made by shaft and arm. 980. EPICYCLIC TRAIN.—If gear wheel Cis fixed, and the arm D moved around…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
