Elementary lessons in steam machinery and the marine steam engine, with a short description of the construction of a battleship (1893)

Langmaid, Joseph, Gaisford, H · London, New York : Macmillan · leaf 199

An illustration from Elementary lessons in steam machinery and the marine steam engine, with a short description of the construction of a battleship, 1893, leaf 199 — is separated and falls into thespace C at the bottom, the steam following the direction of thearrows and going out towards the engines through D. Shouldpriming be going on, the water will accumulate in C, and showin the gauge glass E, which is exactly similar to the boilergauge glass; it is then… … Fig. 80.—Expansion Joint. (Page 177.)

Steam-engines · Marine engines
