Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 255

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 255
24S GEARING. … 981. AUTOMATIC CLUTCH MOTIONFOR REVERSING.-^The bevel wheels B, C arethe drivers in contrary di-rection; D is a double:clutch on the shaft feather.The revolution of the pinon bevel wheel E moves the weighted ball F through the action ofthe bell-crank lever and connecting rod until the ball is past…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
