Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 259

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 259
ELE-VATOR.—V is a compound suctionfan; T, pipe to receiver R; R, areceiver with a wire gauze screento allow dust to be separated from thegrain and carried off through the fan;S, lifting pipe of conical form; N,regulator with a rubber diaphragm toallow the foot nozzle O to regulatethe proportion of… … 8ID.E. ELEVATION Section XII. MOTION AND DEVICES CONTROLLING MOTION. RATCHETS AND PAWLS, CAMS, CRANKS, INTERMITTENT AND STOP MOTIONS, WIPERS, VOLUTE* CAMS, VARIABLE CRANKS, UNIVERSAL SHAFT COUPLINGS, GYROSCOPE, ETC.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
