Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 271

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 271
1060. ROCKING ESCAPEMENT.—Thesection teeth of the wheel pass the eye in therocking cylinder at each quarter, or at eachhalf-revolution when revolving. … 1061. ROTARY AND LONGITUDINALMOTION of a rod between rollers, with theiraxes at an angle. Rollers run in oppositedirections. MOTION AND DEVICES CONTROLLING MOTION. 265 e 69 ^ 1062. RECIPROCATING FEED RATCHET.—For an intermittent feed, one pair of jaws may have areciprocating motion. For continual…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
