Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 375

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 375
and causethe apparatus to make a quarter revolu-tion. Now the latter can not take placewithout the rod, A, B, which was situatedvertically, assuming a horizontal position, and then the balls, A and B,are to each other as were the balls D, C. One must overcome theother and cause the apparatus to… … PERPETUAL MOTION. 371 928. PERPETUAL MOTION. Geared motive power, a is theaxis or shaft on which the wheels are all mounted ; each wheel consists of two parallel rims, h, b, eachof which is connected by radialarms, c, to a boss, d, keyed onthe axis, a; the working partsof each wheel are mounted…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
