Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 287

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 287
A to catch the keyway in any of the speed gears. 1145^. HEDDLE CAM, used Inweav-ing.—The twilling cam K is attached tothe grooved hub L, which slides freely onthe feathered spindle and moves three tnnescne way and returns by a sliding switch overwhich the grooves traverse. 1145^. FERRIS WHEEL.—A…

Mechanical movements
