Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 298

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 298
1183. ANCHOR AND LEVER ESCAPE-MENT for watches. Reeds patent. … 1184. LEVER ESCAPEMENT.—Theanchor pallet B is attached to the lever C E,at the end E of which is a notch to receivethe pin in the balance-wheel disc D. The im-pulse is given to the balance wheel at themiddle of its oscillation by the escape of theteeth from the stop surface to the impulseplanes of…
