Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 306

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 306
1204. LINK CHAIN CUTTER, used incoal-cutting machines. … 1205. DRILL FOR CURVEDHOLES, used in coal mining. Thedrill is on the end of a curved tube, andis driven by a flexible shaft. The tubeis fed forward by a pivoted arm andworm gear.
