Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 314

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 314
top of the rolls ; the iron is heldto the rolls and thrown off afterpassing the chutes. The tailings drop directly into a box.1247 ^. Front end view. 1248. IRON ORE SEPARA-TOR, Buchanan model. Thepulverized ore is fed from a hop-per to a revolving drum, a sectionon each side of which is magne-tized…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
