Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 327

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 327
1303. SIMPLE FRICTION PULLEY.—The self-acting clutch arms act upon the pulley rim inone direction only. When shaft motion is reversed,the pulley is free. … 1304. FRICTION CLUTCH.—A conical-grooved pulley and clutch rim. The clutchslides on the shaft and feather, and is controlledby a lever and carrier in the grooved hub.

Mechanical movements
