Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 33

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 33
48. HEMP ROPE END,doubled in the eye, with twoclips. The doubling in eyeprevents excessive wear. 48a. XEVER SAFETY TRIP, for athrottle valve. The lever L attached toa lanyard extended along the lines ofmachinery enables instant stoppage of anengine in case of accident. 4Sh. LEVER SAFETY TRIP, for…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
