Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 335

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 335
1354. BAND SAW.—Rectihnear motion ofsaw blade from rotary motion of band pulleys,with a tilting saw-table for bevel work. … 1355. TOGGLE-JOINT LEVER PRESS orpunch. A type of toggle-joint used in the oldform of printing and stamping presses. MILL AND FACTORY APPLIANCES. 329

Mechanical movements
