Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 336

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 336
1355. TOGGLE-JOINT LEVER PRESS orpunch. A type of toggle-joint used in the oldform of printing and stamping presses. MILL AND FACTORY APPLIANCES. 329 … 1356. POWER STAMPING PRESS. —Driven^ from a pulley with crank or cam shaft. A miss im-pression IS made by a stop-clutch operated by a foottreadle.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
