Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 346

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 346
1407. TRAVELLING CRANE for shop and foundry-work. May be oper-ated by rope transmis-sion, a long shaft, orelectric motor. 1408. I-BAR TRAVELLING TRAMWAY, aneasily made shop device. The I bar lies sidewise, boltedto brackets from the ceiling. The double trolley can-not run off. 1409. SWING BRACKET…

Mechanical movements
