The principles of pattern making, written specially for apprentices and students in technical schools (1900)
Horner, Joseph Gregory, 1847-1927 · London, New York, Pitman · leaf 65
Fig. 39.Cylinder—Cross Section. ; y- -h-ff K- - -VCC 1 Fig. 40. Cylinder—End View. scription of the pattern and core boxes, shown insucceeding figures. Figs. 41 to 44 illustrate the construction of thecylinder pattern. Fig. 41 is an outside view. Fig.42 is a front view, looked at from the position…
Patternmaking
