Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 349

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 349
A marvel of complexmotions. Hooks andeyes, and any specialshapes of wire-workcan be made onthese machines. 1422. Samples ofwire bending. 342 MILL AND FACTORY APPLIANCES. … 1423. SEAMLESS TUBE MAKING.—The Mannesmann »*process. A, a, conical corrugated rolls: B, guide tube; B, hot bar of iron or steel being pushed throughthe rolls; D, mandrill for wideningthe inside of the tube, the hollow be-ing started by the action of the out-side rolls. 1424. HOPPER AND BELL, for a…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
