Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 35

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 35
48i. STRAIGHT LINE LINK-AGE.—With the joints S and P!«- fixed the joint B will have a ver-trical motion while the link L, Mwill have a horizontal motion paral-lel with the fixed points S, P. LinksP, C, C, M, and B, C, are of equallength. L, B and L, M of equal lengths, as are the short links, S, L… … 48;. THE LEVER AND ITSOFFICE in the pulley governor.Type of the Shepherd governor, inwhich centrifugal force and inertiaare combined for regulating speed. 48^. THE LEVER AND ITSOFFICE in the pulley governor.Type of the Fitchburgh Steam En-gine Company. The lever weightsW, W are thrown out by…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
