Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 354

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 354
1443^?. MODERN COT-TON GIN.— D, nest of saws. E, saw grate betweeneach saw to holdback the seed. A, feeder trough andhopper. J, cylinder brush strip-ping the cotton fibrefrom the saw. F, adjusting lever. K, sliding mote board. MIIvI/ AND FACTORY APPLIANCES. 347 … 1443c. SPOOL WIND-ING MACHINE.—Aworm screw B and geardrives a set of cams R ona cross shaft and oscillatesa lever and thread guide toand fro. The spool spindledriven by friction gear fromthe shaft B.
