Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 354

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 354
14436/. CONICAL ROLLERTHRUST BEARING.—The conicalrollers are held in ring travellers, in-side and outside, which are connectedtogether between the rollers. The conical lines meet at the centerof the shaft. … 1443^. STEAM VULCANIZERfor repairing bicycle tires.—Two steamslabs and tightening screw set on asmall boiler heated by a lamp or torch;steam pressure should be 75 lbs. persquare inch. Small clamps and screwsare attached to the top steam box forvulcanizing other articles. The lowersection is the…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
