Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 364

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 364
DECK BRIDGE TRUSSES.i486. Single strut deck truss for shortspans, 30 to 40 feet. 148 7. Double strut deck trussfor 50 to 70 feet span. 1488. Multi-pie strut decktruss for 100feet span. 1489. BRIDGE TRUSS.^Inclined strut and tie rod for eachpanel,with stiff compression upperchord. Vertical members…

Mechanical movements
