Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 366

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 366
1505. CANTILEVER BRIDGE.—The ends, being anchored,balance all other parts on the piers. This cut shows the principle ofCantilever construction. 1506. SUSPENSION BRIDGES—The old railway bridge at.Niagara. Eight hundred andtv/enty-one feet span. 1507. A four-span suspen-sion bridge. Allegheny…

Mechanical movements
