Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 38

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 38
62. ROPE TRANS-MISSION from verticalto horizontal shaft, withtension slide and weight … 63. ROPE TRANS-MISSION to a movableshaft at right anglesfrom the driving-shaft,^,^with tension slide andweight.

Mechanical movements
