Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 386

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 386
1570. POST CRANE.—Driven by hy-draulic lift under the platform. The boomswings on the post. The rope is carried upthe hollow post … 1571. WHARF CRANE, withtrussed arch jib. Pivoted to turn inany direction. Power shaft turns incrane pivot. 38o MISCELLANEOUS DEVICES.
