Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 393

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 393
1602. ENDLESS CABLEGRIP CAR.—A stationary jawunder the cable. A movable jawon top operated by a grip levelabove. Used for towing mining cars. 1603. STREET RAIL^WAY SWEEPINGCAR. —The cylin-drical sweeper isdriven from the axleby bevel gear.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
