Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 394

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 394
1607. IRON FRAME TURN-TABLE, showing design of cast-iron panels. Wrought-iron top chord. … 1608. SINGLE-CYLIN-DER LOCOMOTIVE.— Centre crank, for narrow-gauge roads. i6o8<2. End view.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
