Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 397

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 397
1623. GAS PRESSURE REGULATOR. —An elastic diaphragm is fastened betweendished discs and connected to a conicalvalve disc by a light adjustable spindle.The pressure for the burners is regulated byring weights at H, and the proper positionof the valve by the nuts on the long screwat the top of the…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
