Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)
Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 481
ce ofvarying speed and power by changing the couple of the batteryhas been retained by the majority of electric vehicle manufactur-ers, among whom there is a very definite tendency toward de-signs permitting of high power outputs at low speeds. This endis attained largely by accurately calculating… … Fig. 350.—Plan Diagram of Single Motor Attached to Rear Axle ThroughHerring-bone Single Reducing Gears. A is the left-hand section ofthe divided rear axle; B, the right-hand section of the rear axle; C, thebrake drum; D, the spiral pinion on the motor shaft driving the wormgear, I, on the…
Automobiles
