Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 402

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 402
r runs forward and is locked by turn-ing into a notch. Centre fire. MISCELLANEOUS DEVICES. 395 1643. REMINGTON RIFLE.—A breech block, operated by a handle, is pulled back toallow the cartridge to becharged by hand, when thebreech and the block arelocked. The hammer strikesa firing pin within the…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
