Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 402

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 402
.^9^ MISCELLANEOUS DEVICES. 1648. WINCHESTER MAGAZINE RIFLE.— The breech lock slidesin line with the barrelby a toggle link, oper-ated by the breech le-ver, which also operatesthe cartridge lever, rais-ing the cartridge to its position for charging. Drawing back of the breech block carries the…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
