Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 58

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 58
il bar, H^, H^, in front of therecord sheet; K, K, winding barrels forthe record sheet driven by a clock move-ment ; M, index dial. 153. PARALLEL MOTION OFTHE INDICATOR. Proportions: c: d\\ d\ ^—nearly. 154. PARALLEL MOTION FOR AN INDI-CATOR.—The curved slot is made proportional,to the length of… … wheel indicate the number of revolutions of the rolling disc. 156. LIPPINCOTT PLAN.IMETER.-R is the fixed point?.T the tracer; ^ is a smooth roundarm on which a scale is laid offfrom the axis; D is a disc with afree motion on the scaled arm.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
