Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 61

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 61
171. TIRE MEASURE COUN-TER.—A wheel running freely in theforks of a handle, is made of a size thatwill roll exactly two feet to a revolution,and graduated in feet and inches. Thesupplementary index is set to allow foilap in welding the tire. MEASUREMENT OP POWER. 55

Mechanical movements
