Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 68

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 68
189. SEE WATER TUBE BOILER.—A series of short straight tubes connecting a hori-zontal steam drum with a rectangular water baseon each side of the furnace. Return tube at backof boiler. STEAM POWER. 61 190. YARROW WATER TUBE BOILER.—Inclined sections of straight tubes from water-headers each side of… … 191. BOYERS WATERTUBE BOILER. —Furnace walls are coils of pipe. Coilsover the fire are connected fromcirculating pipes to steam drum.
