Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 74

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 74
C = S2 X.7854XPX A—(GX B) —(VX A)W … 219. ORIGINAL FORM of the ^olipile or HerosSteam Engine, 130 B.C. A reaction power, suitablefor operation by the use of any gaseous or fluid pres-sure. The original type of several modem motors. 220. STEEPLE ENGINE, with cross-headand slides. 68 STEAM POWER.

Mechanical movements
