Putnam, J. Pickering (John Pickering), 1847-1917 · Boston, Ticknor and Co. · leaf 71
Fig. 42. Smoke-consuming Fireplace of Touet-Chambor. Front View. … Fig. 43. Section. the grate in :i niche, .-is in Figs. 42 and 43, and having two openings intothe Hue. one above, as in the ordinary fireplace, to use when the fire is firsl lighted, and one below to reverse the flame. I [eadded the tubes behind the fire-back to save theheal of the smoke and flame,…
Fireplaces
