Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 81

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 81
74 STEAM POWER. 250. WING THROTTLE VALVE, or ButterflyThrottle, operated by direct connection with a gov-ernor. 251. MULTIPLE PORT PISTON THROTTLEVALVE.—A perfectly balanced valve with throughconnecting rod. … 252. CORLISS VALVEGEAR.—Operated by asingle eccentric througha lever and connecting ~ rods. Steam and exhaustvalves are worked by pinson a rocking wrist plate.The trips on the steam-valve gears are controlled by the governor.
