Mechanics and heat; a text book for collleges and technical schools (1916)
Franklin, William S. (William Suddards), 1863-1930, Macnutt, Barry, 1878-1936, [from old catalog] joint author · New York, The Macmillan company; London, Macmillan & co., ltd. · leaf 105
K —range 16 miles Fig. 31. very large, so that the motion of such a body differs widely fromthe ideal motion described in Art. 36. Thus, Fig. 31 shows theactual orbit of the heavy projectile from a modern high powergun, and the dotted line shows what the orbit would be in avacuum. (d) The air… … is the cause of the curiously curved orbit of a split-shottennis ball, and of a base ball pitched by an expert pitcher. The DYNAMICS. TRANSLATORY MOTION. 91 curved arrows, Fig. 32, show the direction of rotation of a baseball, the arrow M shows the direction of its translatory motion,the arrow F…
Mechanics · Heat
