Mechanics and heat; a text book for collleges and technical schools (1916)

Franklin, William S. (William Suddards), 1863-1930, Macnutt, Barry, 1878-1936, [from old catalog] joint author · New York, The Macmillan company; London, Macmillan & co., ltd. · leaf 409

An illustration from Mechanics and heat; a text book for collleges and technical schools, 1916, leaf 409
arily true. When a rubber band is elongated, the tension of the band increases and a curvemay be plotted of which the abscissas represent elongations and of which the or-dinates represent tensions. Thus, the abscissas of the curve ab in Fig. 38 repre-sent elongations and the corresponding ordinates… … impossible diagram 9>t rubber engine Fig. 39- (1) Increase the length of the band at constant temperature Ti as representedby the line ab. During this process a definite amount of heat Hi must be abstractedfrom the band. (2) Continue to stretch the band, without abstracting heat from it, until…
