Mechanics of engineering. Comprising statics and dynamics of solids: and the mechanics of the materials of constructions, or strength and elasticity of beams, columns, arches, shafts, etc (1888)
Church, Irving P[orter], 1851- [from old catalog] · New York, J. Wiley & sons · leaf 289
Fig. 241. The moment and shear diagrams are drawn in accordancewith these results. FLEXUEE. SAFE LOADS. 277 If the load TV = id is uniformly distributed on the can-tilever, as in fig. 242, by making nO free we have, puttingI(mom. about n) = 0, v—=wx. | rJf=y2tcxi.-. Mm=y2id2= y2 m. Hence the moment…
Mechanics, Applied · Engineering · Strength of materials
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
