Mechanics of engineering. Comprising statics and dynamics of solids: and the mechanics of the materials of constructions, or strength and elasticity of beams, columns, arches, shafts, etc (1888)
Church, Irving P[orter], 1851- [from old catalog] · New York, J. Wiley & sons · leaf 406
and Dynamics. 321. Linear Arch for a Given Upper Contour of Loading, thearch itself being the unknown lower contour. Given theupper curve or limit of load and the depth zQ at crown, re-quired the form of linear arch which will be in equili-brium under the homogenous load between itself and… … Fig. 340. Fig 341. As before, the loading is homogenous, so that theweights of any portions of it are proportional to thecorresponding areas between the curves. (Unity thick-ness 1 to paper.) Now, Fig. 341, regard two consecutivedss of the linear arch as two links or consecutive blocksbearing at…
Mechanics, Applied · Engineering · Strength of materials
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
